| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 1500 | 1650 |
| Power Rating (kW) | 1200 | 1320 |
| Frequency (Hz) | 50 | |
| Engine Model | KTA50-GS8 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BC1650 (Open Type) | BC1650S (Silent Type) |
|---|---|---|
| Length (L) mm | 5600 | 6100 |
| Width (W) mm | 2150 | 2250 |
| Height (H) mm | 2550 | 3050 |
| Tank Capacity (L) | 2760 | 2760 |
| Emission Certification | ---- |
| Number of Cylinders | 16 |
| Cylinder Arrangement | In-line |
| Cycle | Four Stroke |
| Aspiration | Turbocharged and Low Temperature Aftercooled |
| Bore x Stroke | 159 x 159 mm |
| Displacement | 50.3 L |
| Compression Ratio | 15.0:1 |
| Prime Power / Speed | 1287 kW/1500 rpm |
| Standby Power / Speed | 1430 kW/1500 rpm |
| Fuel System | Cumins PT |
| Cooling System | Force Water Cooling Cycle |
| Frequency Droop | ≤ 5% |
| Total Lubrication System Capacity | 47 L |
| Coolant Capacity (Engine Only) | 43.5 L |
| Fuel Consumption (100% Load) | 204 g/kWh @1500 rpm |
| Starter Motor | DC 24V |
| Charge Alternator | DC 24V |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-454C |
| Alternator Rated Power | 1200kw/1500kva |
| Rated Voltage (V) | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Number of Bearing | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Transient State Voltage | ≤-15%～+20% |
