Our 1100kW 1375KVA BOBIG BAUDOUIN diesel generator (Model: 12M33G1500/5) is designed to provide reliable power for a wide range of applications. Backed by the renowned BAUDOUIN brand, it offers high-quality performance and long-term durability.
With a rated power of 1100kW (1375KVA), this generator meets the power needs of various industrial, commercial, and residential applications. The prime power output is stable and efficient, ensuring continuous operation even under heavy loads. Operating at a standard frequency of 50Hz, it is suitable for most electrical equipment in the market.
Powered by the 12M33G1500/5 BAUDOUIN engine, this generator combines advanced technology with high-quality manufacturing. The engine is known for its high torque, fuel efficiency, and low emissions. Running at 1500 RPM, it provides a smooth and consistent power supply while minimizing wear and tear on engine components.
| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 1375 | 1513 |
| Power Rating (kW) | 1100 | 1210 |
| Frequency (Hz) | 50 | |
| Engine Model | 12M33G1500/5 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (According to customer requirements) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
PRP: Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97. A 10% overload capability is available for a period of 1 hour within a 12-hour operation.
ESP: The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
| Engine Model & Manufacturer | 12M33G1500/5 (BAUDOUIN) |
| Number of Cylinders / Valves | 12 / 48 |
| Cylinders Arrangement | At Vee |
| Bore x Stroke (mm) | 150 x 185 |
| Displacement (L) | 39.2 |
| Thermodynamic Cycle | Diesel 4 stroke |
| Mean Piston Speed (m/s) | 9.25 |
| BMEP @ ESP (Bar) | 26.94 |
| Cooling System | Liquid (water + 50% antifreeze) |
| Injection System | Direct |
| Fuel System | Mechanical Pump |
| Aspiration | Turbocharged and Aftercooled |
| Compression Ratio | 15:1 |
| Flywheel Housing | SAE 0 |
| Flywheel | 18" |
| Number of Teeth on Flywheel Ring Gear | 194 |
| Inertia of Flywheel (kg•m²) | 7.18 |
| Inertia of Crankshaft (kg•m²) | 4.52 |
| Emission Standard | N/A |
| Overall Dimensions with Radiator (L x W x H) (mm) | 3525 × 2241.5 × 2243 |
| Engine Dry Weight without Radiator (kg) | 3590 |
| Engine Dry Weight with Radiator (kg) | 4575 |
| Engine Wet Weight with Radiator (kg) | 5024 |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-404G |
| Alternator Rated Power | 1100kW/1375kVA |
| Rated Voltage (V) | 230V/400V |
| Rated Frequency | 50Hz |
| Connecting Type | 3 Phase and 4 Wire |
| Number of Bearings | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Transient State Voltage | ≤-15%~+20% |
| Model | BBDA1513 (Open Type) | BBDA1513S (Silent Type) |
|---|---|---|
| Length (mm) | 4800 | ** |
| Width (mm) | 1550 | ** |
| Height (mm) | 2550 | ** |
| Tank Capacity (L) | 2530 | ** |
BOBIG products come with a one-year or 1000-hour warranty (whichever comes first) from the ex-factory date. During the warranty period, we provide free replacement of easily damaged spare parts caused by production or material quality issues. Our professional after-sales service team is available 24/7 to provide technical support, maintenance, and repair services.
We are an electrical machinery manufacturer integrating technological research, production, and sales. With a total factory area of 10,000 square meters and 160 employees (including 20 technicians), we specialize in gasoline generators, diesel generators (5-2000kVA), gas generators, and pumps. Our company holds ISO9000 Quality System Certification and utilizes advanced testing equipment to ensure product quality.
