| Parameter | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 1500 | 1650 |
| Power Rating (kW) | 1200 | 1320 |
| Frequency (Hz) | 50 | |
| Engine Model | KTA50-GS8 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| Power Factor | 0.8 | |
| Rated Voltage (V) | 400/230 (customizable) | |
| Fuel Tank Operation Time | ≥ 8 hours @ 75% load | |
| Model Type | BC1650 (Open) | BC1650S (Silent) |
|---|---|---|
| Length (mm) | 5600 | 6100 |
| Width (mm) | 2150 | 2250 |
| Height (mm) | 2550 | 3050 |
| Tank Capacity (L) | 2760 | 2760 |
| Engine Model & Manufacturer | KTA50-GS8 (Cummins) |
| Number of Cylinders | 16 |
| Cylinder Arrangement | In-line |
| Cycle | Four Stroke |
| Aspiration | Turbocharged and Low Temperature Aftercooled |
| Bore x Stroke | 159 x 159 mm |
| Displacement | 50.3 L |
| Compression Ratio | 15.0:1 |
| Fuel System | Cummins PT |
| Cooling System | Force Water Cooling Cycle |
| Total Lubrication System Capacity | 47 L |
| Coolant Capacity (engine only) | 43.5 L |
| Alternator Brand | BOBIG |
| Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-454C |
| Rated Power | 1200kW/1500kVA |
| Rated Voltage | 230V/400V |
| Rated Frequency | 50Hz |
| Connecting Type | 3 Phase and 4 Wire |
| Protection Grade | IP23 |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating |
| Insulation Class | H class |
| Voltage Regulation, Steady State | ≤±1% |
