| Specification | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 15 | 17 |
| Power Rating (kW) | 12 | 13 |
| Frequency (Hz) | 50 | |
| Engine Model | 4Z2.3-G11 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| Power Factor (PF) | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 | |
| Fuel Tank Operating Time | ≥ 8 hours @ 75% load | |
| Model | BSD17 (Open Type) | BSD17S (Silent Type) |
|---|---|---|
| Length (mm) | 1250 | 1950 |
| Width (mm) | 610 | 850 |
| Height (mm) | 940 | 1100 |
| Tank Capacity (L) | 28 | 28 |
| Engine Model & Manufacturer | 4Z2.3-G11 (SDEC) |
| Engine Type | In-line, 4 strokes, water-cooled |
| Combustion Type | Direct injection |
| Cylinder Type | Wet cylinder liner |
| Number of Cylinders | 4 |
| Bore × Stroke | 85 × 100 mm |
| Displacement | 2.3 lit. |
| Compression Ratio | 18:1 |
| Firing Order | 1-3-4-2 |
| Fuel Injection Advance Angle | 14-17° |
| Dry Weight | 260 kg |
| Dimension | 919×565×760mm |
| Rotation | CCW viewed from flywheel |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-164D |
| Alternator Rated Power | 12kW/15kVA |
| Rated Voltage | 230V/400V |
| Rated Frequency | 50Hz |
| Connecting Type | 3 Phase and 4 Wire |
| Number of Bearing | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Engine | Alternator | Fuel System | Generating Set |
|---|---|---|---|
| Water Jacket Preheater | PMG excitation | 12/24 hour base tank | Deepsea, ComAp, Smartgen controllers |
| Oil Preheater | Space heater | Bunded fuel tank | Trailer |
| Oil manual pump | Winding temperature measuring | External fuel tank | Tools with the machine |
| Automatic fuel feeding | |||
| Switch between external tank and base tank |
