| Specification | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 10 | 11 |
| Power Rating (kW) | 8 | 9 |
| Frequency (Hz) | 50 | |
| Engine Model | 3Z1.1-G42 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (According to customer requirements) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Engine Model & Manufacturer | 3Z1.1-G42 (SDEC) |
| Engine Type | In-line, 4 strokes, water-cooled |
| Combustion Type | Direct injection |
| Cylinder Type | Wet cylinder liner |
| Number of Cylinders | 3 |
| Bore × Stroke | 78 × 78.4 mm |
| Displacement | 1.1 lit. |
| Compression Ratio | 18:1 |
| Firing Order | 1-2-3 |
| Fuel Injection Advance Angle | Electronic control |
| Dry Weight | 110 kg |
| Dimension | 530x390x590mm |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-164B |
| Alternator Rated Power | 8kw/10kva |
| Rated Voltage (V) | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Number of Bearing | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Model | BSD11 (Open type) | BSD11S (Silent type) |
|---|---|---|
| Length (L) mm | 1250 | 1900 |
| Width (W) mm | 610 | 850 |
| Height (H) mm | 940 | 1100 |
| Tank Capacity (L) | 18 | 18 |
