| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 2250 | 2475 |
| Power Rating (kW) | 1800 | 1980 |
| Frequency (Hz) | 50 | |
| Engine Model | YCC105TA3000-G31 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (Customizable) | |
| Fuel Tank Capacity | ≥ 8h @ 75% load | |
| Engine Model & Manufacturer | YCC105TA3000-G31 (YUCHAI) |
| Number of Cylinders | 16 |
| Cylinder Arrangement | Vertical |
| Cycle | Four Stroke |
| Aspiration | Turbocharged, water-air intercooled |
| Bore x Stroke | 200 x 210 mm |
| Cubic Capacity | 105.56 L |
| Compression Ratio | 13.5:1 |
| Prime Power/Speed | 2005 kW/1500 rpm |
| Standby Power/Speed | 2228 kW/1500 rpm |
| Fuel Consumption (100% load) | 205.7 g/kWh @1500 rpm |
| Alternator Brand | BOBIG |
| Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-454G |
| Rated Power | 1800kW/2250kVA |
| Protection Grade | IP23 |
| Insulation Class | H Class |
| Voltage Regulation | ≤±1% |
| Model | Length (mm) | Width (mm) | Height (mm) | Tank Capacity (L) |
|---|---|---|---|---|
| BYU2475 (Open Type) | 7280 | 2715 | 3164 | 4140 |
| BYU2475S (Silent Type) | 5600 | 2200 | 2550 | 4140 |
